every ime i compile my program this error appear idon't know why
Error: Port "r" does not exist in primitive "dff" of instance "U4"
this is my program
library ieee;
use ieee.std_logic_1164.all;
entity usr is
port(clk,srsi,slsi:in bit;
s :in bit_vector(1 downto 0);
I: in bit_vector(3 downto 0);
A: out bit_vector(3 downto 0));
end;
architecture universal_shift_register of usr is
component mux is
port(a0,a1,a2,a3:in bit;
S: in bit_vector (1 downto 0);
f: out bit );
end component;
component dff is port
(clk,d:in bit;
r: out bit );
end component ;
signal d0:bit;
signal d1:bit;
signal d2:bit;
signal d3:bit;
signal da0:bit;
signal da1:bit;
signal da2:bit;
signal da3:bit;
begin
U0:mux port map(da0,da1,slsi,i(0),s,d0);
U1:mux port map (da1,da2,da0,i(1),s,d1);
U2:mux port map(da2,da3,da1,i(2),s,d2);
U3:mux port map(da3,srsi,da2,i(3),s,d3);
U4:dff port map(clk,d0,da0);
U5:dff port map(clk,d1,da1);
U6:dff port map(clk,d2,da2);
U7:dff port map(clk,d3,da3);
A(3)<=da3;
A(2)<=da2;
A(1)<=da1;
A(0)<=da0;
end;
library ieee;
use ieee.std_logic_1164.all;
entity mux is
port(a0,a1,a2,a3:in bit;
S: in bit_vector (1 downto 0);
f: out bit );
end;
architecture mux4_1 of mux is
begin
process (S)
begin
case S is
when "00" =>
f <= a0;
when "01" =>
f <= a1;
when "10" =>
f <= a2;
when "11" =>
f <= a3;
end case;
end process;
end;
library ieee;
use ieee.std_logic_1164.all;
entity dff is port
(clk,d:in bit;
r: out bit );
end;
architecture ff of dff is
begin
process (clk,d)
begin
if(clk'event and clk<= '1')then
r<=d;
end if;
end process;
end;
i want your help
