altera_msgdma with unaligned access: lost data and stuck busy

Hello, I've developed an application on a Terasic DE10-Lite board which has a MAX10 and an SDRAM chip onboard, using Quartus 18.1 for this. In my design I have used a nios II/f core (w/o cache), the...
Memory
ShengN_altera's avatar
ShengN_altera
Icon for Super Contributor rankSuper Contributor
2 years ago

Hi,


Could you provide the whole design file for duplicating?

There're some software library files missing.


Thanks,

Regards,

Sheng


etome's avatar
etome
Icon for New Contributor rankNew Contributor
2 years ago

Hello Sheng,

sorry for the delay, I've cleaned up the software files and left only what is needed for the test to compile.

My setup is a bit "twisted", you will likely need a copy of the toolchain, I've attached it. I had to modify the Makefile to have it work under WSL (to escape paths), and there is a patch for the bsp makefile (it removes 2 source files) under the buffering folder.

If you start with a clean bsp, then I'd start with

patch ../buffering_fast_bsp/Makefile bsp_makefile.patch

The toolchain is compiled to use picolibc and it is used for both the BSP and the test application, so you'll have to copy the file Software/buffering/picolibc_custom.specs to the BSP directory (as I've done under buffering_fast_bsp).

I've run make clean_all to clean all the build files, I think you can use the BSP I've provided and not bother with all that above.

The toolchain was compiled under ubuntu 22.04, it is not static linked.

Cheers,

etome
