Command Line compile causing issue with Quartus Standard vs Quartus Prime Pro

Hello support team.

I am developing for the MAX10 FPGA, which is being used as a management/controller system for a Stratix 10 device on the same board. Naturally, I have both Quartus Standard and Quartus Prime Pro installed since the Max10 only works in Quartus Standard. It is a nios build and I am using the eclipse nios tool to write a custom bootloader.

The issue I have is this:

Until now, I have always compiled my Max10 build in the GUI of Quartus Standard. This has always worked with no issues.

Recently, I switched to a command line workflow to speed things up. So, I am compiling using the command

quartus_sh --flow compile max10_project

As you can see in the screenshot this is compiling with the Standard edition compiler, which is what I want.

The compilation completes without error.

After this, I can still use the output files(.sof, .pof) with no issue. However, I can no longer open the project in the GUI. If I open it in Quartus Standard, the error states this was built in quartus Prime Pro and must be opened there. If I try to open it in Quartus Prime Pro it tells me that the MAX10 is not supported in Prime Pro and will not open it. So, essentially after command line compile, my .pof and .sof and .sopcinfo files are fine, but the project can no longer be opened so I can make changes/updates to Qsys...etc.

Any ideas on a workaround to this issue?? I checked the documentation for command line flow for quartus standard on Nios developers handbook and it just says use quartus-sh --flow compile. I dont see any tags that I can add to make the project use a certain file structure that will support Quartus Standard.

Thank you.

Best Regards,

Jacob
