Simulation Runtime Error

Hi Lauren,

Assuming you have done the compilation

1. Go to your project, select your hdl and testbench, then click simulate on the window option.
2. A start simulation window will pop out
3. In the library (for you gate_work i guess) select your testbench and hdl file, right click and click simulate.
4. A window simulation will pop up. select your desired signal in the object window, select them and add wave (depend on what signal you want to simulate)
5. Click run on the window option to run the simulation.

Thanks,

Regards
