Periodic Pulses Pattern

Hello,

I'm a new Verilog programmer and still rely on examples to write code.

I didn't find any example of what I need.

I need to generate two pulses periodicaly like this following schema:

clk is the base of the period (pulse every 8 ticks for example).

pulse1: rises 3 ticks after positive edge of clk and falls 2 ticks later.

pulse2: rises 4 ticks after positive edge of clk and falls 3 ticks later.

I'd like also generates the pulses for a limited number (N) of periods, 1 ≤ N < ∞.

I suppose I have to use temporisation conditions (#t) but didn't success to synchronize them to posedge of clk.

Thank for your help.

7 Replies

  • Nurina's avatar
    Nurina
    Icon for Regular Contributor rankRegular Contributor

    Hello,


    Thank you for using Intel Communities.

    Please allow some time while I investigate.


    Regards,

    Nurina


  • Nurina's avatar
    Nurina
    Icon for Regular Contributor rankRegular Contributor

    Hello,


    Are you trying to do this for simulation only? Are you trying to have a testbench to show this behaviour?

    Can you share what you currently have?


    Regards,

    Nurina


  • Anonymous's avatar
    Anonymous

    Thank you to your answer,

    Yes it is for a testbench only. I have no result because I didn't find how writing the code to obtain the desired result.

    Best regards.

    Daniel

  • Nurina's avatar
    Nurina
    Icon for Regular Contributor rankRegular Contributor

    Hello,


    Can you attach the code you have written so we can work from there?


    Thanks,

    Nurina


  • Anonymous's avatar
    Anonymous
    Here are the expected periodicaly outputs of the test bench:
    I tried this code. What is the problem?
    `timescale 1us/1ns
    module Pulses(clk, pulse1, pulse2);
    output clk, pulse1, pulse2;
    wire c, p1, p2;
    initial
    begin
    c = 0;
    p1 = 0;
    p2 = 0;
    repeat(1000) //1000 cycles repeated
    begin
    #0 c = 1;
    #1 c = 0;
    #2 p1 = 1;
    #1 p2 = 1;
    #1 p1 = 0;
    #2 p2 = 0;
    #1 ;
    end
    assign clk = c;
    assign pulse1 = p1;
    assign pulse2 = p2;
    end
    endmodule

    Thank you

  • Nurina's avatar
    Nurina
    Icon for Regular Contributor rankRegular Contributor

    Hello,

    That doesn't look like a testbench. How are you simulating this? Are you using ModelSim/QuestaSim?

    I tried using QuestaSim and managed to get the output you want.

    First of all, a testbench shouldn't have any ports declaration -> module Pulses(clk, pulse1, pulse2);

    It should be empty like so -> module Pulses ();

    And I don't think you can use assign in testbench.

    Please refer to the verilog files I'm attaching. periodic_pulses.v is the top verilog file in your Quartus project and periodic_pulses_tb.v is the testbench.

    Follow the steps here to compile and run simulation, it should be the same for Quartus Lite:

    QuestaSim: https://www.intel.com/content/www/us/en/docs/programmable/703090/21-1/simulation-quick-start.html

    ModelSim: https://www.intel.com/content/www/us/en/docs/programmable/683248/18-0/simulation-quick-start.html

    Regards,

    Nurina

    p/s: If any answer from the Intel Support is helpful, please feel free to provide rating with 4/5 survey on the support provided.

  • FvM's avatar
    FvM
    Icon for Super Contributor rankSuper Contributor

    Hello,

    apart from the point that outputs have no purpose in a testbench, the problem in your original code are of different kind.

    Assignment must take place outside the initial statement.

    `timescale 1us/1ns

    module Pulses(clk, pulse1, pulse2);

    output reg clk, pulse1, pulse2;
    reg c, p1, p2;

    initial
    begin
    c = 0;
    p1 = 0;
    p2 = 0;
    repeat(1000) //1000 cycles repeated
    begin
    #0 c = 1;
    #1 c = 0;
    #2 p1 = 1;
    #1 p2 = 1;
    #1 p1 = 0;
    #2 p2 = 0;
    #1 ;
    end
    end

    assign clk = c;
    assign pulse1 = p1;
    assign pulse2 = p2;

    endmodule
