Where is the SDRAM controller IP in Quartus 21 Lite?

HI, This is for MAX10 (10M08), NIOS, BeMicro dev. board. I trying to get I2C core IP to work but I think my design run out of ram. I'm using the internal MAX10 ram now. I said I think because I d...
Rodo's avatar
Rodo
Icon for Occasional Contributor rankOccasional Contributor
3 years ago

Well... after installing Quartus Lite v17.x thru 21.x I can say that the SDRAM controller IP core was removed from Quartus Lite v21.x. There is a message in the platform designer for Quartus Lite 20.x that says "... the SDRAM controller IP will only be included in Quartus Standard in future releases". Just in case you don't know: The "standard" version is one of the paid versions. So I'm downgrading to Quartus Lite v20.1.1.
